Vertical Agitator
Professional Solids Control Equipment
CHINA KOMAL vertical agitator is professional solids control equipment designed for oil and gas drilling operations. Featuring high-quality construction and reliable performance, it provides efficient solids control for drilling fluid systems in demanding drilling conditions.
Technical Features
- Patent gearbox reducer - Higher reliability and much better working performance
- Lubrication oil free - For whole lifetime maintenance-free operation
- Long running time - Over 6000 hours under suitable maintenance
- Compact design - Much smaller footprint than traditional agitators
- Increased mixing rate - Help to increase mud mixing rate by 25%
- Energy saving - Much more energy efficient than traditional mud agitator
Technical Parameters
| Agitator Model | KJB/L-7.5 | KJB/L-5.5 | KJB/L-4 |
|---|---|---|---|
| Gear Motor Model | KZ200 | KZ100 | KZ50 |
| Power | 7.5kw (10hp) | 5.5kw (7.5hp) | 4kw (5.5hp) |
| Voltage / Frequency | Ex Standard / 460V/60HZ, 380V/50HZ or customized | ||
| Ex Standard | ExdIIBt4 / IEC EX / ATEX for option | ||
| Transmission Ratio | 22 | ||
| Motor Shaft Rotation Speed | 1500 rpm | ||
| Agitator Impeller Rotation Speed | 66 rpm | ||
| Impeller Shaft Agitating Torque | 840 N.M | 620 N.M | 450 N.M |
| Weight | 238 kg | 231 kg | 219 kg |
| Max. Height | 540 mm | 540 mm | 529 mm |
| Impeller Max. Diameter | 500~900mm (50mm step, customized) | ||
| Agitator Shaft Length | 500~2125mm (25mm step, customized) | ||
Applications
- Mud tank agitation - Keep drilling solids in suspension
- Fluid mixing - Enhance mud mixing rate by 25%
- Prevent sedimentation - Maintain uniform mud properties
- Energy efficient operation - Lower power consumption than traditional agitators
