Mud Gas Separator
Professional Solids Control Equipment
CHINA KOMAL mud gas separator is professional solids control equipment designed for oil and gas drilling operations. Featuring high-quality construction and reliable performance, it provides efficient solids control for drilling fluid systems in demanding drilling conditions.
Technical Features
- Bottom discharge design - Slurry and liquid discharged from bottom, working liquid level adjusted with liquid distributor
- No solid accumulation - Solid phase does not accumulate in separator
- Special gas removal pipeline - Quickly remove gas, improve processing efficiency
- Combined separation technology - Combines centrifugal separation with physical shock separation and vacuum separation
- Shock absorber installation - On elbow liquid supply, can be replaced according to wear conditions
- Extended service life - Wear-resistant design prolongs equipment life
Technical Parameters
| Model | KF1000 | KF1200 |
|---|---|---|
| Tank Diameter | 1000 mm | 1200 mm |
| Thickness | 8 mm | 10 mm |
| Capacity | 280 m³/h (1200 gpm) | 320 m³/h (1400 gpm) |
| Inlet/Outlet Diameter | 4 / 10 inch | 6 / 10 inch |
| Vent Line | 8 inch | 8 inch |
| Weight | 2000 kg | 3800 kg |
| Dimension (mm) | 2000×2000×5860 | 2200×2200×6634 |
Applications
- Gas separation from drilling mud - Remove entrained gases safely
- Kick control - Handle gas kicks during drilling
- Well control operations - Critical safety equipment
- High capacity gas handling - Up to 1400 gpm processing
