Single Arm Elevator Links
Professional Drilling Equipment
The Single Arm Elevator Links connect the elevator to the traveling block, transmitting lifting force during pipe handling.
Key Features
- Standards - API Spec 8A, 8C, SY/T5035
- Material - High quality alloy steel forging
- Analysis - Finite-element strength checking
- Testing - Electrical stress measurement
- Types - Single arm and double arm
- Surface - Sand blasting
- Custom - Length can be custom-made
Technical Specifications
| Model | DH150 | DH250 | DH350 | DH500 |
|---|---|---|---|---|
| Rated load (Ibf) | 303492 | 505820 | 708148 | 1000360 |
| Working length (ft) | 5.91 | 8.86 | 10.83 | 12.46 |
| Overall dimension (ft) | 6.50×0.89×0.33 | 9.51×1.18×0.36 | 11.48×1.27×0.43 | 12.68×1.61×0.52 |
| Weight (Ib) | 132.28 | 330.69 | 498.24 | 868.61 |
Applications
- Connecting elevators
- Hoisting operations
- Pipe handling
- Casing running
