OIL WELL A1700PT Mud Pump Parts
CHINA KOMAL supplies comprehensive spare parts for OIL WELL A1700PT mud pumps, including liners, liner packing, valves, valve seats, pistons, rods, and all wear components. All A1700PT parts are manufactured to OEM specifications with strict quality control for reliable performance and extended service life in demanding drilling conditions.
Our OIL WELL A1700PT parts are fully interchangeable with original equipment and offer superior value with competitive pricing and immediate availability.
Liners & Liner Packing (7 1/2× 12)
| Size | LINER | LINER PACKING |
|---|---|---|
| 4" | 0284-40 | KMG-0753 |
| 4½" | 0284-44 | KMG-0754 |
| 5" | 0284-50 | KMG-0742 |
| 5½" | 0284-54 | KMG-0743 |
| 6" | 0284-60 | KMG-0745 |
| 6¼" | 0284-62 | KMG-0770 |
| 6½" | 0284-64 | KMG-0746 |
| 6¾" | 0284-66 | KMG-0755 |
| 7" | 0284-70 | KMG-0756 |
| 7¼" | 0284-72 | KMG-0757 |
| 7½" | 0284-74 | KMG-0758 |
*Also available in small OD 0283-XX
| Gaskets | Part No. | |
|---|---|---|
| Valve Cover Gasket | KMG-0750 | |
| Cylinder Head Gasket | N/A | |
Valves & Valve Seats
| Type | 4 WEB | FULL OPEN | G2 | 3 WEB | ROUGHNECK |
|---|---|---|---|---|---|
| VALVE (Urethane Insert) | U5C-EEF | 7FO-V1 | 1560985 | 202PZL482A | RN7-V1 |
| VALVE (Rubber Insert) | 5C-EEF | N/A | N/A | 202PZL483A | N/A |
| VALVE SEAT | 7DD-B1 | 7FO-S1 | 1561370 | 202PZL039 | RN7-S1 |
| VALVE SPRING | 5710-110 | 5710-115L | 1560702 | 5710-110 | 5710-110L |
| VALVE INSERT (Red Thunder) | UDD-7BHT | N/A | N/A | N/A | N/A |
| VALVE INSERT (Urethane) | UDD-7B | 7FO-SI | 1560557 | 201PZL106 | RN7-I |
| VALVE INSERT (Rubber) | DD-7B | N/A | N/A | 202PZL106 | N/A |
| VALVE SEAT PULLER HEAD | 1700-7 | 1700-7FO | 1700-7G2 | 1700-7R | 1700-7FO |
Pistons
| Piston Size | Bonded Pistons | Imperial Piston | Imperial Rubber Kits | Rubber Bonded | Long Life (Urethane) |
|---|---|---|---|---|---|
| 4" | RT-400 | I40HK14/15 | I40HK | RB-400 | LL-400 |
| 4½" | RT-440 | I44HK14/15 | I44HK | RB-440 | LL-440 |
| 5" | RT-500 | I50HB14/15 | I50HB | RB-500 | LL-500 |
| 5½" | RT-540 | I54HB14/15 | I54HB | RB-540 | LL-540 |
| 6" | RT-600 | I60HB14/15 | I60HB | RB-600 | LL-600 |
| 6½" | RT-640 | I64HL14/15 | I64HL | RB-640 | LL-640 |
| 7" | RT-700 | I70HL14/15 | I70HL | RB-700 | LL-700 |
| 7½" | N/A | I74HL14/15 | I74HL | N/A | N/A |
*1/4 Size are available upon request
Rods
| Item | Part No. |
|---|---|
| PISTON ROD | 0283-C |
| SUB ROD | 0283-A |
| CONNECTING STUD | 0283-D |
| EXTENSION ROD | 18-0284 |
| ROD CLAMP | 24-0284 |
| PISTON ROD NUT | 7403364 |
Fluid End Module and Accessories
| Item | Part No. | Description | Qty per Pump |
|---|---|---|---|
| 1 | 10-300-181 | Discharge Module, Studded (Included Items 2-8) | 3 |
| 2 | - | Discharge Module, Only | 3 |
| 3 | 49-001-292 | Stud - Discharge Manifold | 12 |
| 4 | 75-511-754 | Nut - Discharge Manifold | 12 |
| 5 | 49-002-837 | Stud - Frame | 12 |
| 6 | 75-510-128 | Nut - Frame | 12 |
| 7 | 10-300-184 | 1 Wear Plate - Liner | 6 |
| 8 | 20-100-008 | Gasket - Liner Wear Plate | 6 |
| 9 | 75-832-234 | Cap Screw, Self Locking | 24 |
| 10 | 20-200-004 | Valve Guide Bushing | 6 |
| 11 | 10-300-004 | Valve Guide | 6 |
| 12 | 10-300-011 | Gasket - Valve Cover | 6 |
| 13 | 10-300-005 | Valve Cover | 6 |
| 14 | 10-300-183 | Liner Adapter | 3 |
| 15 | 10-300-182 | Nut - Liner Adapter | 3 |
| 16 | 10-300-185 | Spacer Ring - Liner | 3 |
| 17 | 10-300-186 | 2 Centering Sleeve - Liner | 3 |
| 18 | 10-300-201 | Seal - Suction Manifold | 3 |
| 19 | 99-609-345 | Seal - Discharge Manifold | 3 |
¹Offered in Plain Carbon or Stainless Steel ²Not used with 6½" and larger diameter liners.
